9.8 Additional Functions
Overview
Press the DIVERSE FUNCTION soft key to call the additional
functions. The TNC then displays the following soft keys:
Function Soft key Page
FN 14:ERROR
Output of error messages Page 288
FN 15:PRINT
Unformatted output of texts or
Q parameter values Page 293
FN 16:F-PRINT
Formatted output of texts or Q parameter
values Page 294
FN 18: SYS-DATUM READ
Read system data Page 298
FN 19:PLC
Send values to the PLC Page 304
FN 20:WAIT FOR
Synchronize NC and PLC Page 305
FN 25:PRESET
Set the datum during program run Page 307
FN 26:TABOPEN
Open a freely definable table Page 423
FN 27:TABWRITE
Write to a freely definable table Page 423
FN 28:TABREAD
Read from a freely definable table Page 424
