Programming: q parameters – HEIDENHAIN iTNC 530 (340 49x-05) User Manual
Page 36
36
10.1 Entering Miscellaneous Functions M and STOP ..... 338
10.2 Miscellaneous Functions for Program Run Control, Spindle and Coolant ..... 340
10.3 Miscellaneous Functions for Coordinate Data ..... 341
Programming machine-referenced coordinates: M91/M92 ..... 341
Activating the most recently entered datum: M104 ..... 343
Moving to positions in a non-tilted coordinate system with a tilted working plane: M130 ..... 343
10.4 Miscellaneous Functions for Contouring Behavior ..... 344
Smoothing corners: M90 ..... 344
Insert rounding arc between straight lines: M112 ..... 344
Do not include points when executing non-compensated line blocks: M124 ..... 345
Machining small contour steps: M97 ..... 346
Machining open contours corners: M98 ..... 348
Feed rate factor for plunging movements: M103 ..... 349
Feed rate in millimeters per spindle revolution: M136 ..... 350
Feed rate for circular arcs: M109/M110/M111 ..... 350
Calculating the radius-compensated path in advance (LOOK AHEAD): M120 ..... 351
Superimposing handwheel positioning during program run: M118 ..... 353
Retraction from the contour in the tool-axis direction: M140 ..... 354
Suppressing touch probe monitoring: M141 ..... 355
Delete modal program information: M142 ..... 356
Delete basic rotation: M143 ..... 356
Automatically retract tool from the contour at an NC stop: M148 ..... 357
Suppress limit switch message: M150 ..... 358
10.5 Miscellaneous Functions for Laser Cutting Machines ..... 359
Output the programmed voltage directly: M200 ..... 359
Output voltage as a function of distance: M201 ..... 359
Output voltage as a function of speed: M202 ..... 360
Output voltage as a function of time (time-dependent ramp): M203 ..... 360
Output voltage as a function of time (time-dependent pulse): M204 ..... 360
