First Steps with the iTNC 530
1
.3 Pr
ogr
amming the First P
a
rt
U
Depart the contour
U
Select the departure function DEP CT
U
Center angle?
Enter the departure angle, e.g. 90°, and
confirm with the ENT key
U
Circle radius?
Enter the departure radius, e.g. 8 mm,
and confirm with the ENT key
U
Feed rate F=?
Enter the positioning feed rate, e.g.
3000 mm/min and confirm with the ENT key
U
Miscellaneous function M?
Switch off the coolant,
e.g. M9, with the END key: The TNC saves the entered
positioning block
U
Retract the tool: Press the orange axis key Z in order
to get clear in the tool axis, and enter the value for the
position to be approached, e.g. 250. Confirm with the
ENT key
U
Confirm Radius comp.: RL/RR/no comp? by pressing
the ENT key: Do not activate the radius compensation
U
Confirm Feed rate F=? with the ENT key: Move at
rapid traverse (FMAX)
U
Miscellaneous function M?
Enter M2 to end the
program and confirm with the END key: The TNC
saves the entered positioning block
Further information on this topic
Complete example with NC blocks: See “Example: Linear
movements and chamfers with Cartesian coordinates,” page 209
Creating a new program: See “Creating and Writing Programs,”
page 99
Approaching/departing contours: See “Contour Approach and
Departure,” page 192
Programming contours: See “Overview of path functions,” page
200
Programmable feed rates: See “Possible feed rate input,” page 103
Tool radius compensation: See “Tool radius compensation,” page
183
Miscellaneous functions (M): See “Miscellaneous Functions for
Program Run Control, Spindle and Coolant,” page 340
