Interpolation „ Linear in 4 axes
„ Linear in 5 axes (subject to export permit) (software option 1)
„ Circular in 2 axes
„ Circular in 3 axes with tilted working plane (software option 1)
„ Helix:
Combination of circular and linear motion
„ Spline:
Execution of splines (3rd degree polynomials)
Block processing time
3-D straight line without radius
compensation „ 3.6 ms
„ 0.5 ms (software option 2)
Axis feedback control „ Position loop resolution: Signal period of the position encoder/1024
„ Cycle time of position controller: 1.8 ms
„ Cycle time of speed controller: 600 µs
„ Cycle time of current controller: minimum 100 µs
Range of traverse „ Maximum 100 m (3937 inches)
Spindle speed „ Maximum 40 000 rpm (with 2 pole pairs)
Error compensation „ Linear and nonlinear axis error, backlash, reversal spikes during circular movements,
thermal expansion
„ Stick-slip friction
Data interfaces „ One each RS-232-C/V.24 and RS-422/V.11 max. 115 kilobaud
„ Expanded interface with LSV-2 protocol for external operation of the TNC over the
interface with HEIDENHAIN software TNCremo.
„ Ethernet interface 100BaseT
approx. 2 to 5 megabaud (depending on file type and network load)
„ USB 1.1 interface
For pointing (mouse) devices and block devices (memory sticks, hard disks, CD-ROM
drives)
Ambient temperature „ Operation: 0 °C to +45 °C
„ Storage: –30 °C to +70 °C
