HEIDENHAIN iTNC 530 363
1
1
.1 Ov
erview of Special F
unctions
Program defaults menu
U Select the program defaults menu
Functions for contour and point machining
menu
U Select the menu for functions for contour and point
machining.
Function Soft key Description
Define the workpiece blank Page 99
Define the material Page 415
Define global cycle parameters See User’s Manual
for Cycles
Select datum table See User’s Manual
for Cycles
Function Soft key Description
Assign contour description See User’s Manual
for Cycles
Define a simple contour formula See User’s Manual
for Cycles
Select a contour definition See User’s Manual
for Cycles
Define a complex contour
formula See User’s Manual
for Cycles
Define regular machining pattern See User’s Manual
for Cycles
Select the point file with
machining positions See User’s Manual
for Cycles
