Page 69: 6 w o rk piece set u p 1.6 workpiece setup

background image

HEIDENHAIN iTNC 530

69

1

.6 W

o

rk

piece Set

u

p

1.6 Workpiece Setup

Select the correct operating mode

Workpieces are set up in the Manual Operation or Electronic
Handwheel

mode

U

Press the operating modes key: The TNC goes into

the Manual Operation mode

Further information on this topic

„

Manual mode: See “Moving the Machine Axes,” page 498

Clamp the workpiece

Mount the workpiece with a fixture on the machine table. If you have
a 3-D touch probe on your machine, then you do not need to clamp the
workpiece parallel to the axes.

If you do not have a 3-D touch probe available, you have to align the
workpiece so that it is fixed with its edges parallel to the machine
axes.
