636 Tables and Overviews
1
8
.2 Pin La
y
outs and Connecting Cables f
o
r the D
a
ta Int
e
rf
aces
Non-HEIDENHAIN devices
The connector pin layout of a non-HEIDENHAIN device may differ
considerably from that of a HEIDENHAIN device.
It depends on the unit and the type of data transfer. The table below
shows the connector pin layout on the adapter block.
Adapter block
363 987-02
Connecting cable 366 964-xx
Female Male Female Color Female
1 1 1 Red 1
2 2 2 Yellow 3
3 3 3 White 2
4 4 4 Brown 6
5 5 5 Black 5
6 6 6 Violet 4
7 7 7 Grey 8
8 8 8 White/Green 7
9 9 9 Green 9
Housing Housing Housing Ext. shield Housing
