HEIDENHAIN iTNC 530
301
9.8 A
d
ditional F
unctions
2
3
Z axis
3
-
Programmed feed rate (–1: no feed rate programmed)
Active tool compensation, 200
1
-
Tool radius (including delta values)
2
-
Tool length (including delta values)
Active transformations, 210
1
-
Basic rotation in MANUAL OPERATION mode
2
-
Programmed rotation with Cycle 10
3
-
Active mirrored axes
0: mirroring not active
+1: X axis mirrored
+2: Y axis mirrored
+4: Z axis mirrored
+64: U axis mirrored
+128: V axis mirrored
+256: W axis mirrored
Combinations = sum of individual axes
4
1
Active scaling factor in X axis
4
2
Active scaling factor in Y axis
4
3
Active scaling factor in Z axis
4
7
Active scaling factor in U axis
4
8
Active scaling factor in V axis
4
9
Active scaling factor in W axis
5
1
3-D ROT A axis
5
2
3-D ROT B axis
5
3
3-D ROT C axis
6
-
Tilted working plane active / inactive (–1/0) in a Program
Run operating mode
7
-
Tilted working plane active / inactive (–1/0) in a Manual
operating mode
Path tolerance, 214
8
-
Tolerance programmed with cycle 32 or MP 1096
Active datum shift, 220
2
1
X axis
Group name, ID number
Number
Index
Meaning
