Grass Valley XtenDD DD User Manual
Page 81
5. Connection and Startup
5 - 19
Planning and Installation - Rev. 3 / 04.2005
5.3.2.6 Aux Panel Connectors
AUX SELECTION
DC POWER IN
Item
No:
Socket / Connector
Description
Socket type
Connector type
Function
1
DC POWER IN
3-pin D-type
female
DC input (+5V) for Aux panel.
Connected with DC POWER OUT on the main
panel.
2
AUX SELECTION
37-pin D-type
female
Internal connection to main panel.
Detailed information regarding the panel-internal connection can be found in the following diagram.
