2. Technical Data
2 - 2
Planning and Installation - Rev. 3 / 04.2005
Aspect ratio:
16:9
Overall Input/
PGM output delay:
< 0.5 line dependent on standard
Blanking:
switchable:
transparent for background signal or blanked
2.1.4
POWER SUPPLY MAINFRAME
Line voltage:
200 V to 240 V AC $10 % (SH-1/2/3/4-BM)
100 V to 240 V AC $10 % (SH-1/2S-BM)
Line current:
13 A max
Line frequency:
50 Hz / 60 Hz $5 %
Power Consumption:
max. 1200W (SH-1/2/3/4-BM)
max. 700 W (SH-1/2S-BM)
Touch (leakage) currents:
< 2.5 mA (for each power supply)
2.1.5
MECHANICAL DATA SH-1/2/3/4-BM STANDARD MAINFRAME
Dimensions:
19” rackframe, 12 + 1
*)
RU high
Hight 533 mm (20.98”)
Width 483 mm (19”)
Depht 554 mm (21.8”)
*)
1 RU under the electronics box has to be
left free for ventilation, security tube
and slide-in rails
Weight:
< 154 lbs / 70 kg.
2.1.6
MECHANICAL DATA SH-1/2S-BM SMALL MAINFRAME
Dimensions:
19” rackframe, 7 RU high
Hight 310 mm (12.2”)
Width 483 mm (19”)
Depht 508 mm (20”)
Weight:
< 77 lbs / 35 kg (incl. all options)
2.1.7
ENVIRONMENTAL DATA
Storage temperature:
-4
°
F to +158
°
F
(-20°C to +70°C)
Operating Temperature:
+41
°
F to +95
°
F
(+5
°
C to +35
°
C)
Relative humidity:
<= 80% non-condensing
