4. Installing Control Panels
4 - 21 Planning and Installation - Rev. 3 / 04.2005
4.3.2 MOUNTING WITH “ALL-IN-ONE” MOUNTING FRAME
D Trace careful the position of panel on the desk. The exact dimensions of the
main panel and the side panels you can find in section “Desk cut-outs”.
D Cut-out the opening in the desk.
D Unpack each individual piece.
ATTENTION!
Electrostatic sensitive devices. Observe the precautions for handling!
D Mount the “All-in-one” mounting frame with the screws on the rear side of the
panel.
