3. Installing Mainframes
3 - 3
Planning and Installation - Rev. 3 / 04.2005
3.2.2
SMALL MAINFRAME SH-1/2S-BM
The mainframe of the switcher is located in a closed 19-inch frame which houses
the individual plug-in cards of the video and control electronics as well as the power
supply units.
17.6” = 447 mm
19” = 483 mm
12.2”
7RU
21,3” = 540 mm
20” = 508 mm
310.3 mm
(incl. connectors)
