7. Initial Installation
7 - 12 Planning and Installation - Rev. 3 / 04.2005
The mainframe may contain from top to bottom the following modules in the front:
Slot 1: RAM Recorder (Option) RY 3050
FX Processor (Option) RY 3060
Slot 2: Key / Wipe Processor (M/E1 stage) RY 3020
Slot 3: M/E Processor (M/E1 stage) RY 3010
Slot 4: Input Processor RY 3642
Slot 5: Aux Processor RY 3031
Slot 6: M/E Processor (P/P stage) RY 3410
Slot 7: Key / Wipe Processor (P/P stage) RY 3020
Slot 8: Controller (up to #155) RY 3156
space (#156 or higher) -
Slot 9: Genlock (up to #155) RY 3081
Controller/Genlock (#156 or higher) RY 3490
Power Slot 1: Redundant Power Supply (Option) RC 3470
Power Slot 2: Power Supply RC 3470
Fan Slot: Fan Unit cpl. RC 3304
The following modules are installed in the rear of the mainframe:
D Serial Input Modules 1 to 5 RC 3610
RC 3611
RC 3612
RC 3613
RC 3614
D Serial Output Modules 1 to 3 RC 3620
RC 3621
RC 3622
D Control Module RC 3630
Mainframe type definition:
D SH-1S-BM mainframe is equipped with the P/P stage.
D SH-2S-BM is equipped with P/P and M/E1 stage.
