5. Connection and Startup
5 - 49 Planning and Installation - Rev. 3 / 04.2005
MULTIPORT RS-232
Mainframe
Pin Signal
25-pin D-type
female
1
13
14
25
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19-25
Chassis Ground
P13 Transmit Data
P13 Receive Data
P13 Clear to Send
P13 Request to Send
not used
P13 Signal Ground
not used
P14 Signal Ground
P14 Transmit Data
P14 Receive Data
P14 Clear to Send
P14 Request to Send
P15 Signal Ground
P15 Transmit Data
P15 Receive Data
P15 Clear to Send
P15 Request to Send
not used
GPI/GPO
Panel
Pin Signal
25-pin D-type
female
1
13
14
25
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
GPI In 6+
GPI In 5+
GPI In 4+
GPI In 3+
GPI In 2+
GPI In 1+
GPI Out 6
GPI Out 5
GPI Out 4
GPI Out 3
GPI Out 2
GPI Out 1
Chassis Ground
GPI In 6-
GPI In 5-
GPI In 4-
GPI In 3-
GPI In 2-
GPI In 1-
GPI Out 6~
GPI Out 5~
GPI Out 4~
GPI Out 3~
GPI Out 2~
GPI Out 1~
For details refer to the mainframe connector on the next page.
