7. Initial Installation
7 - 9 Planning and Installation - Rev. 3 / 04.2005
Slot Board Description
Slot 14 Genlock (up to Serial No. 154) or
Controller/Genlock (Serial No. 155 and higher)
RY 3081 or
RY 3490
Slot 15 Controller (up to Serial No. 154) or
space (Serial No. 155 and higher)
RY 3156 or
space
The following modules are installed in the rear of the mainframe:
D Connection Unit RC 3001
D Midplane RC 3002
D Backplane RC 3003
D Input Module RY 3004
D Output Module RY 3005
D Genlock Input Module RY 3008
D Fan Unit cpl. RC 3006
D LAN Box RC 2167
Mainframe type definition:
D SH-1-BM mainframe is equipped with the P/P stage.
D SH-2-BM is equipped with P/P and M/E1 stage.
D SH-3-BM is equipped with P/P, M/E1 and M/E2 stage.
D SH-4-BM is equipped with P/P, M/E1, M/E2 and M/E3 stage.
