34
Introduction
Features
Analog Video Router
The 2RU analog video router is mechanically similar to other 32×32 routers with BNC connectors
except that the input and output BNCs are grouped in blocks of 16:
Fig. 2-56: Rear View, 32×32 Analog Video Router
The 32×4 analog video router has 4 outputs:
Fig. 2-57: Rear View, 32×4 Analog Video Router
Analog Audio Router
The 2RU analog audio router is slightly deeper (57 mm) than any of the other 32×32 routers. Its
inputs and outputs use DB25 connectors:
Fig. 2-58: Rear View, 32×32 Analog Audio Router
22 23 24 21
17 18 19 20
OUTPUTS
26 27 28
30 31 32
25
29 25 26 27 28
17 18 19 20
21 22 23 24
9 10 11 12
13 14 15 16
1 2 3 4
5 6 7 8
10 11 12
14 15 16
2 3 4
6 7 8
OUTPUTS
9
13
1
5
O
LOOP
THRU
E146905
K50 29 30 31 32
• • • •
Inputs 1–16, BNC, 75W
Outputs 1–16, BNC, 75W Outputs 17–32, BNC, 75W
Inputs 17–32, BNC, 75W
25 26 27 28
17 18 19 20
21 22 23 24
9 10 11 12
13 14 15 16
1 2 3 4
5 6 7 8
2 3 4 1
O
LOOP
THRU
E146905
K50 29 30 31 32
OUTPUTS
• • • •
Inputs 1–16, BNC, 75W Outputs 1–4, BNC, 75W Inputs 17–32, BNC, 75W
INPUTS
INPUTS
17-24 25-32
OUTPUTS
OUTPUTS
1-8 9-16
INPUTS
INPUTS
OUTPUTS
OUTPUTS
33-40 41-48
49-56 57-64
I/O 17–24 I/O 25–32
I/O 9–16 I/O 1–8 Fan I/O 33–40
I/O 49–56
I/O 41–48
I/O 57–64
