120
Technical Details
Power Specifications
Power Specifications
CR Series Router and Remote Panel Module Power Specifications
PS0001 Power Supply Specifications
Specification Detail
DC power External power supply: 12VDC ± 10%, 5A.
Power consumption 15 W nominal (8×8 3Gig, SWB, SD)
10 W nominal (8×8 3Gig, SWB, SD, non-reclocked)
15 W nominal (16×4 3Gig, SWB, SD)
10 W nominal (16×4 3Gig, SWB, SD, non-reclocked)
20 W nominal (16×16 3Gig, SWB, SD)
15 W nominal (16×16 3Gig, SWB, SD, non-reclocked)
25 W nominal (32×4 3Gig, SWB, SD)
20 W nominal (32×4 3Gig, SWB, SD, non-reclocked)
35 W nominal (32×32 3Gig, SWB, SD)
25 W nominal (32×32 3Gig, SWB, SD, non-reclocked)
5 W nominal (8×8AES)
5 W nominal (16×4 AES)
6 W nominal (16×16 AES)
10 W nominal (32×32 AES)
7 W nominal (8×8 analog video)
7 W nominal (16×4 analog video)
9 W nominal (16×16 analog video)
16 W nominal (32×32 analog video)
15 W nominal (8×8 analog audio)
15 W nominal (16×4 analog audio)
18 W nominal (16×16 analog audio)
40 W nominal (32×32 analog audio)
12 W nominal (16-port machine control)
22 W nominal (32-port machine control)
33 W nominal (16×2 CQX router)
77 W max (CR6464-3Gig router)
55 W max (CR6464-AES router)
Regulatory UL listed and CE compliant.
Specification Detail
AC power 90–264 VAC (127–300VDC), 47–447Hz.
Inrush current < 50A at 230VAC, cold start, at 25°C,
Input current < 2.0A rms at 115VAC; < 1.0A at 230VAC.
DC power
< 60W, 12VDC, 5A (5.4A peak), Regulation ± 2%. Ripple < 120mV.
Efficiency Efficiency > 80% at full load typical, 115VAC.
Weight 1.06 lb (0.48 kg).
Regulatory UL listed and CE compliant.
