Page 152

3-106

Section 3 — Controls & Menus

Proc Amp Menus

Press the white

[Proc Amp]

top menu button to display the Proc

Proc Amp Menu Functions:

(XPT SELECT)

—Highlights a crosspoint in the display table for

processing amplifier adjustment.

[CLEAR PROC AMP]

, [CLEARALL PROC AMPS]—These two selections

allow you to clear a proc amp for a particular crosspoint or clear
all proc amps to standard settings.

[PROC AMP ENABLE]

—Turns processing amplifiers on or off for all

crosspoint buses.

[MORE PROC>]

displays additional processing amplifier

adjustments.

(LUMA GAIN)

—Adjusts the range of luminance (brightness).

(LUMA OFFSET)

—Adjusts the dc base level of luminance.

(CHROMA SATURATION)

—Adjusts color saturation.

(HUE)

—Appears when you select [MORE PROC]. Adjusts the hue of

the colors.

(U OFFSET)

—Appears when you select [MORE PROC]. Adjusts offset

of U color component. A positive U value adds more blue to the
picture. Negative U adds more yellow to the picture.

(V OFFSET)

—Appears when you select [MORE PROC]. Adjusts offset

of the V color component. A positive V value adds more red to the
picture. Negative V adds more green.
