Jupiter L-S Series Control Panels Installation and Operating Manual 49
Section
4
Jupiter System Configuration
The following overview of L-S series panel configuration assumes that the
reader is familiar with the Jupiter Facility Control System. Please refer to
the Jupiter CM-4000 Installation and Operating Manual for specific informa-
tion.
MPK Table Entries
The Jupiter MPK table is used for configuration purposes. The example
shown in
Figure 26 applies to the system shown in Figure 23 on page 43 .
Figure 26.
JEP1 CP-ESLAN 01
JEP2 CP-ESLAN 02
1
MPK Devices
MPK
Expansion
Pass
Board
CM1
Port Address Input Sets Output Sets Level Set Overide Set Sequence Set
2 CM1 KXYZINP KXYZOUT KXYZLEV
Devices word
In Panel Out Panel
JEP64 CP-ESLAN 64 64 CM1 KXYZINP KXYZOUT KXYZLEV
KXYZINP KXYZOUT K KXYZLEV
Type
Device
8536_03
MPK Devices table
MPK Devices - This column is used to create a name, up to eight characters in
length, for each L-S panel. This name must be unique system-wide.
Device Type - Select type “ CP-ESLAN ” on the pull-down menu.
Expansion - For L-S series panels, leave unchecked.
Password - (Password level does not need to be entered.)
Board - Name of CM-4000 associated with this panel. The source of this
name is the Network Description table.
Port - Not used for LAN-only installation.
Address - Panel address from 01 to 64. Must be unique for panels associated
with the same CM-4000. L-S panels are normally shipped with a panel
address of “01.” This number is referred to as the “Device Number” on the
IP configuration page and “ID” within the L-S menu system.
