Avenue 9430 Flexible Matrix Router Installation, Configuration and Operations Guide
Command Response Message
Description: This is the response to all valid GV TEN-XL commands sent to the router.
Syntax:
Video source number assigned to requested destination.
Valid range is ‘0’ to ‘9’ (30H to 39H).
Audio source number. Not used.
Always reported as ‘0’ (30H).
Power supply okay. Not used.
Always reported as okay: ‘3’ (33H).
Example: Router receives a Status Request command for destination number 1. Assume that
video source 6 is assigned to this destination.
Request: In Hex 02 30 31 05
In ASCII 01
Response: In Hex 36 30 33
In ASCII 603
Notes: The Audio Source number and the Power Supply portions of the response are required
by the protocol, but the values returned are to be ignored.
