can communicate with each other.
4.7.2 PVLAN Port Configuration
PVLAN Port Configuration page allows configure Port Configuration and Private
VLAN Association.
Private VLAN Association (PVLAN)
Secondary VLAN: After the Isolated and Community VLAN Type is assigned in
Private VLAN Configuration page, the VLANs are belonged to the Secondary VLAN
and displayed here.
Primary VLAN: After the Primary VLAN Type is assigned in Private VLAN
Configuration page, the secondary VLAN can associate to the Primary VLAN ID.
Select the Primary VLAN ID here.
Note: Before configuring PVLAN port type, the Private VLAN Association should
be done first.
Port Configuraion
PVLAN Port Type :
Normal: The Normal port is None PVLAN ports, it remains its original VLAN
setting.
Host: The Host type ports can be mapped to the Secondary VLAN.
Promiscuous: The promiscuous port can be associated to the Primary VLAN.
VLAN ID: After assigned the port type, the web UI display the available VLAN ID
the port can associate to.
94
