4 Feature Configuration
This chapter explains how to configure PMI Managed software features. There
are four ways to access the switch: Serial console, Telnet, Web browser and
SNMP.
PMI Managed Switch provides both in‐band and out‐band configuration methods.
You can configure the switch via RS232 console cable if you don’t attach your
admin PC to your network, or if you lose the network connection to your PMI
switch. This is so‐called out‐band management. It wouldn’t be affected by the
network performance.
The in‐band management means you can remotely manage the switch via the
network. You can choose Telnet or Web‐based management. You just need to
know the device’s IP address. Then you can remotely connect to its embedded
HTML web pages or Telnet console.
Westermo web management page is developed by Java. It allows you to use a
standard web‐browser such as Microsoft Internet Explorer, or Mozilla, to
configure and interrogate the switch from anywhere on the network.
Note: IE 5.0 or later versions do not allow Java applets to open sockets by default.
Users have to directly modify the browser settings to selectively enable Java
applets to use network ports.
Following topics are covered in this chapter:
4.1 Command Line Interface (CLI) Introduction
4.2 Basic Setting
4.3 Port Configuration
4.4 Power over Ethernet
4.5 Network Redundancy
4.6 VLAN
4.7 Private VLAN
4.8 Traffic Prioritization
4.9 Multicast Filtering
4.10 SNMP
4.11 Security
4.12 Warning
4.13 Monitor and Diag
4.14 Device Front Panel
4.15 Save
4.16 Logout
