TFTP Server mode: In this mode, the switch acts as TFTP client. Before you do so,
make sure that your TFTP server is ready. Then please type the IP address of TFTP
Server and Backup configuration file name. This mode can be used in both CLI
and Web UI.
TFTP Server IP Address: You need to key in the IP address of your TFTP Server
here.
Backup/Restore File Name: Please type the correct file name of the
configuration file.
Configuration File: The configuration file of the switch is a pure text file. You can
open it by word/txt read file. You can also modify the file, add/remove the
configuration settings, and then restore back to the switch.
Startup Configuration File: After you saved the running‐config to flash, the new
settings will be kept and work after power cycle. You can use show startup‐config
to view it in CLI. The Backup command can only backup such configuration file to
your PC or TFTP server.
Once you finish selecting and configuring the settings, click on Backup or Restore to run
Once you finish selecting and configuring the settings, click on Backup or Restore to
run
Default Configuration File: The switch provides the default configuration file in the
system. You can use Reset button, Reload command to reset the system.
Running Configuration File: The switch’s CLI allows you to view the latest settings
running by the system. The information shown here is the settings you set up but
haven’t saved to flash. The settings not yet saved to flash will not work after power
recycle. You can use show running‐config to view it in CLI.
Technical Tip:
