The port trust is set CoS only ok.
Port Setting – Trust
Mode‐ CoS First
rst
Switch(config)# interface fa1
Switch(config‐if)# qos trust cos‐fi
The port trust is set CoS first ok.
Port Setting – Trust
Mode‐ DSCP Only Switch(config)# interface fa1
Switch(config‐if)# qos trust dscp
The port trust is set DSCP only ok.
Port Setting – Trust
Mode‐ DSCP First
rst
Switch(config)# interface fa1
Switch(config‐if)# qos trust dscp‐fi
The port trust is set DSCP first ok.
Display – Queue
Scheduling
eighted Round Robin (Use an
Switch# show qos queue‐sched
QoS queue scheduling scheme : W
8,4,2,1 weight)
Display – Port Setting ‐
Trust Mode
Q ode :
only
Switch# show qos trust
oS Port Trust M
Port Trust Mode
‐‐‐‐‐+‐‐‐‐‐‐‐‐‐‐‐‐
1 DSCP first
2 COS
3 COS only
4 COS only
5 COS only
6 COS only
7 COS only
8 COS only
9 COS only
10 COS only
Display – Port Setting –
CoS (Port Default Priority) S rt‐cos
Po
0
witch# show qos po
rt Default Cos :
Port CoS
‐‐‐‐‐+‐‐‐‐
1 7
2
3 0
4 0
5 0
6 0
7 0
8 0
9 0
10 0
CoS‐Queue Mapping
Format
S ig)# qos cos‐map
PRIORITY Assign an priority (7 highest)
witch(conf
Switch(config)# qos cos‐map 1
QUEUE Assign an queue (0‐3)
Note: Format: qos cos‐map priority_value queue_value
Map CoS 0 to Queue 1
The CoS to queue mapping is set ok.
Switch(config)# qos cos‐map 0 1
Map CoS 1 to Queue 0 Switch(config)# qos cos‐map 1 0
The CoS to queue mapping is set ok.
Map CoS 2 to Queue 0 Switch(config)# qos cos‐map 2 0
The CoS to queue mapping is set ok.
Map CoS 3 to Queue 1 Switch(config)# qos cos‐map 3 1
The CoS to queue mapping is set ok.
