Section 5
CONFIGURATION
OVERVIEW
The MCE 300 can be customized to your specifications through switch settings and the L (Load
Configuration) command. The RS232 devices connected to the unit, the card layout, and the
features you desire enabled will determine the specific configuration for your unit. The L (Load
Configuration) command must be properly loaded to allow use of the D (Load Data), S (Encode
Cards), and R (Read Cards) commands. The configuration is not used for the M (Encode Cards -
Raw Data) and N (Read Cards - Raw Data) commands.
SWITCH SETTINGS
There are three switch settings used in the configuration of your MCE 300. These switches are
located on the Microprocessor PCB located inside your unit. These switch settings are set at the
factory as indicated in the chart below. If it is necessary to change these switch settings follow the
procedure below.
1.
Turn off the power to the MCE 300 and unplug it from the AC outlet.
2.
Remove the screws from the top cover of the unit.
3.
Remove the top cover.
The switches are designated as SW2 on the PCB. There are eight switches grouped together in
one block. These switches control:
SW-2
On or Closed Off or Open
8 Optional Printer Available Not Available *
7 Label Printer Available Not Available *
6 Card Exit Mode Rear Front *
5-1 Not used *Factory Setting
4.
Change the switches to your desired configuration.
Optional Printer - An optional hard copy printer is available and connected to the AUX port of
the unit.
Label Printer - An optional label printer is available and connected to the AUX port of the unit.
Both of these switches should be enabled if:
- Two separate printers are available
- One printer is available that will be performing both functions
Card Exit Mode - This determines where the card will exit from after encoding or reading.
5. Replace the top cover.
6.
Replace the screws on the top cover.
NOTE: The switch settings are read when the unit is turned on. Changing the switch
settings while power is on will not change the configuration until power for the unit
is cycled (OFF/ON).
