Logix 3400IQ Digital Positioner FCD LGENIM3402-00 – 0/07
34
Table 11.3 Logix 3400IQ-011 : AO-011 (AO)
Configuration File Data Comments
(17) CAS_IN =
STATUS = Good_Cascade::NonSpecific:NotLimited
VALUE = 0
(18) SP_RATE_DN = 1.#INFPV/Sec
(19) SP_RATE_UP = 1.#INFPV/Sec
(20) SP_HI_LIM = 100
(21) SP_LO_LIN = 0
(22) CHANNEL = 0x0001
(23) FSTATE_TIME = 0Sec
(24) FSTATE_VAL = 0
(25) BKCAL_OUT =
STATUS = Good_Cascade::NonSpecific:NotLimited
VALUE = 0
(26) RCAS_IN =
STATUS = Good_Cascade::NonSpecific:NotLimited
VALUE = 0
Initialized value = Un-initialized, must be set to valid value
(27) SHED_OPT = NormalShed_NormalReturn
(28) RCAS_OUT =
STATUS = Good_Cascade::NotInvited:NotLimited
VALUE = 83.04
(29) UPDATE_EVT =
UNACKNOWLEDGED = Unacknowledged
UPDATE_STATE = Un-initialized
TIME_STAMP = 01/01/72 00:00:00 (MM/DD/YY HH:MM:SS)
STATIC_REVISION = 0x0002
RELATIVE_INDEX = 0x001b
(30) BLOCK_ALM =
UNACKNOWLEDGED = Unacknowledged
ALARM_STATE = Active-Not Reported
TIME_STAMP = 10/07/98 11:53:59 (MM/DD/YY HH:MM:SS)
SUB_CODE = OutOfService
VALUE = 0x00
(31) WSP =
STATUS = Good_Cascade::NonSpecific:NotLimited
VALUE = 83.04
(32) BLOCK_TEST =
BLOCK_TEST = 0xb9
BLOCK_TEST = 0x00
BLOCK_TEST = 0x00
BLOCK_TEST = 0x00
BLOCK_TEST = 0x00
BLOCK_TEST = 0x00
BLOCK_TEST = 0x0f
BLOCK_TEST = 0xc4
Constantly increases
