MBT-5000 L-Band Up/Down Converter System MN-MBT5000
Front Panel Operation Revision 4
5–12
5.2.3 SELECT: Monitor Menu Branch
Monitor: Faults Mask
Event-Log LPT
Use the ◄ ► arrow keys to select from the submenu choices shown, and then press ENTER.
The submenus available from the SELECT: Monitor menu branch are as follows:
Submenu Sect Function
Faults 5.2.3.1 Displays the active faults for the base unit and the converters.
Mask 5.2.3.2 Used to configure Alarm Mask (MSK) conditions.
Event-Log 5.2.3.3 Used to displays stored events, and to clear the events.
LPT 5.2.3.4 (Low Power Threshold) Used to configure Low Power Threshold.
5.2.3.1 Monitor: Faults
Live Faults: Unit ConvA
ConvB (◄ ► E)
Use the ◄ ► arrow keys to select Unit, ConvA, or ConvB, and then press ENTER. If you select
Unit, the highest level fault for the base unit appears. If no Unit faults exist, the message “ Unit
Fault: No Errors” displays.
Press ENTER to return to the previous menu.
If you select ConvA or ConvB, the highest fault for that converter appears. If no Converter faults
exist, the message “ ConvX Fault: No Errors” (where ConvX means ConvA or ConvB)
displays.
Press ENTER to return to the previous menu.
5.2.3.2 Monitor: Mask
Alarm Mask: Power ExtRef
ConvA ConvB LNA PS (◄ ►E)
Use the ◄ ► arrow keys to select Power (when optionally configured for Power Monitoring),
ExtRef, ConvA, ConvB, LNA, or PS, and then press ENTER.
For each menu selection, three typical options are available. Using the ExtRef menu as an
example:
Ext Ref Lock Detect:
Fault Alarm Masked (◄ ►E)
