MBT-5000 L-Band Up/Down Converter System MN-MBT5000
Serial-based Remote Product Management Revision 4
7–20
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of arguments
(Note that all arguments are ASCII numeric codes between 48 and 57)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code and
Qualifier)
Response to query
(Target to
Controller)
Redundant
Mute Mode
CRM= 1 byte Command or Query.
Determines how the offline unit handles the mute state during a redundant switchover condition.
If the redundant mute mode is off, the offline unit will be muted. If the redundant mute mode is
on, the offline unit's mute state will not be changed.
0 = Off
1 = On
Default Value: 0
Example: <1/CRM=0’cr’
>0001/CRM=’cr’’lf’
CRM=
CRM?
CRM? CRM=x
(same format as
Command
arguments)
LNA Current
Window Enable
(BDC only)
CWE= 1 bytes Command or Query.
Allows t he us er t o enable t he c urrent w indow al arm/fault. I f di sabled, t he L CW v alue w ill be
retained, but unused.
Default Value: 0
Example: <1/CWE=0’cr’
>0001/CWE=’cr’’lf’
CWE =
CWE?
CWE *
CWE? CWE =x
(same format as
Command
arguments)
Operating RF
Frequency
FRE=xxxxx.xxx 9 bytes Command or Query.
Sets, in MHz, valid Operating RF frequency.
For Ku BDC Tri-Band:
FRE values: 10950-11700 MHz a LO of 10000 MHz is activated
FRE values: 11700-12200 MHz a LO of 10750 MHz is activated
FRE values: 12250-12750 MHz a LO of 11300 MHz is activated
For Ku BDC Dual Band:
FRE values: 10950-11700 MHz a LO of 10000 MHz is activated
FRE values: 11700-12750 MHz a LO of 10750 MHz is activated
Example: FRE=11300.000‘cr’
Note: Operating Frequency cannot be changed for the offline unit when in redundancy mode.
FRE=
FRE?
FRE*
FRE? FRE=x….x
(See Description of
Arguments)
Global
Converter
Configuration
GCC= variable length Command or Query.
Used to set up and query the global status of the BUC/BDC.
Example: GCC=aa.aa;b;ccccc.cc; ‘cr’ where:
aa.aa = attenuation in dB (ATT)
b = mute state, 0 = un-muted, 1 = muted (MUT)
ccccc.ccc = frequency in MHz (FRE, Ku BDC only, other units will display xxxxx.xxx)
Note: This command can only be queried for the offline unit when in redundancy mode.
GCC=
GCC?
GCC*
GCC? GCC=x….x
(See Description of
Arguments)
