MBT-5000 L-Band Up/Down Converter System MN-MBT5000
Serial-based Remote Product Management Revision 4
7–11
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
(Note that all arguments are ASCII numeric codes between 48 and 57)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code and
Qualifier)
Response to query
(Target to
Controller)
Faults and
Status
N/A 4 bytes Query Only.
Unit returns the current fault and status codes for the Base Unit, Converter A and B, in the form
abcd, where:
a = Base Unit Faults:
0 = No faults
1 = +12V Power Supply 1
2 = +12V Power Supply 2
3 = +5V Power Supply 1
4 = +5V Power Supply 2
5 = +7.8V Power Supply
6 = Flash Checksum
7 = FPGA Done
8 = External Ref Lock Detect
9 = Converter A Not Inserted
A = Converter B Not Inserted
B = Switch Fault
b, c = Converter A and B Faults:
0 = No faults
1 = Synthesizer Lock Detect
2 = Heat-sink Temperature
3 = LNA Current Supply (BDC only)
4 = Low Forward RF Power (BUC only)
d = New Faults:
0 = No change in fault status since last check
1 = Change in fault status, since last check
N/A FLT? FLT=abcd
d=Change in fault
status since last poll.
Note: Each section
has faults listed in
order of priority. For
each section, only the
highest priority fault is
returned. There are
maybe multiple faults
for each section, but
only the highest fault
is returned.
Initialize Events
Pointer
IEP= None Command only.
Resets internal pointer to allow RNE? Queries to start at the beginning of the stored events log.
Example: IEP=
IEP=
IEP?
IEP*
N/A N/A
Software Image IMG= 1 byte Command or Query.
Current Active software image, where:
1=Bulk Image # 1 currently active
2=Bulk Image # 2 currently active
Example: IMG=1 (which is Image #1 active)
IMG=
IMG?
IMG*
IMG#
IMG? IMG=x
(See Description of
Arguments)
