Advanced Operation
1 Select the ZONE2 mode using the AMP
button.
Adjustment steps that need to be performed
prior to surround sound playback in ZONE2
2 Test Tone
• Before playing with the surround function, be sure to use
the test tones to adjust the playback level from the
different speakers. This adjustment can be performed with
the system setup (
page 122, 123) or from the remote
control unit, as described below.
• Adjusting with the remote control unit using the test tones
is only possible in the “Auto” mode and only effective in
the STANDARD (DOLBY/DTS SURROUND) modes. The
adjusted levels for the different modes are automatically
stored in the memory.
1 Select the ZONE2 mode using the AMP
button.
2
Press the CH SEL/ENTER button.
• The “Channel Vol.” screen appears.
2 Channel Level
• After adjusting using the test tones, adjust the channel
levels either according to the playback sources or to suit
your tastes, as described below.
3 Press the CURSOR D D, H H or CH SEL/ENTER
button to select the speaker.
The channel switches as shown below each time the
CH SEL/ENTER button is pressed.
4
Press the CURSOR F F or G G button to adjust the
level.
The adjustment range for the different channels is
+12.0 dB to –12.0 dB.
The sound from the subwoofer can be completely cut
by lowering the SW (subwoofer) setting one additional
step from –12.0 dB (setting it to “OFF”).
FADER
SR
SBL SL SBR
FL C FR SW
ZONE2 surround back speakers are only displayed when
“7.1ch” is selected for the ZONE2 channel output
setting at “Channel Setup” (
page 126 ~ 128).
When the ZONE2 surround back speaker setting is set
to “1spkr” for “Speaker Configuration”, this is set to
“SB”.
• For instructions on making the settings ( page 120 ~ 125).
1 Select the ZONE2 mode using the AMP
button.
2
Press the SYSTEM SETUP button.
• The ZONE2 system setup menu appears.
The screen displayed depends on the settings made at
“Channel Setup” (
page 126 ~ 128).
System setup for multi-zone
• This makes possible to make the optimum setting for the
speaker systems used in ZONE2.
3 Press the CURSOR F F or G G button to adjust all
the speakers to the same volume.
4 After completing the adjustment, press the
TEST TONE button again.
Example: When “ZONE2” is set for a 5.1 or 7.1 channel
system
Example: When “ZONE2” is set for a STEREO or MONO
2
Press the TEST TONE button.
• The “Test Tone” screen appears.
