154

Advanced Setup – Part 2

Video Setup

Page

Default settings

Audio Input Setup

Page

Default settings

3. Audio Input Setup

104

Digital In
Assignment

CD

DVD

VDP

TV

DBS

VCR-1

VCR-2

COAX

1

COAX

2

COAX

3

COAX

4

COAX

5

OPT 1

OPT 2

This assigns the digital input terminals for the
different input sources.

Input

source

Digital

Inputs

1

CDR /

TAPE

OPT 4

VCR-3

VCR-4

OPT 3

V.AUX

OPT 5

OPT 6

2

EXT.IN Setup

Set the EXT.IN terminal playback method.

Mode = DSP, Surr.B = NOT USED, S.Back = NOT USED,

SW Level = +15 dB, Input ATT. = OFF

Mode = DSP, SW Level = +15 dB, Input ATT. = OFF

106

Input
Function
Level

The playback level is corrected individually for the different
input sources.

TUNER PHONO

CD

CDR /

TAPE

DVD

VDP

TV

0 dB

0 dB

0 dB

0 dB

0 dB

0 dB

0 dB

3

VCR-2

0 dB

DBS VCR-1

0 dB

0 dB

VCR-3 VCR-4

0 dB

V.AUX

0 dB

4

Function
Rename

The names of the different input function can be changed
as desired and displayed on the display.

106, 107

5

IEEE1394
Assignment

The connected IEEE1394 device can be automatically
identified to assign the input source.

107

6

IEEE1394
Auto
Function

Set the function for associating playback of the connected
IEEE1394 device on or off.

Auto Function = OFF

108

7

Tuner
Presets

FM stations are received automatically and
stored in the memory.

A1 ~ A8

B1 ~ B8

C1 ~ C8

D1 ~ D8

E1 ~ E8

87.5/89.1/98.1/107.9/90.1/90.1/90.1/90.1 MHz

520/600/1000/1400/1500/1710 kHz, 90.1/90.1 MHz

90.1 MHz

90.1 MHz

90.1 MHz

Auto
Preset
Memory

F1 ~ F8

G1 ~ G8

90.1 MHz

90.1 MHz

Preset channels that are not used often can be
skipped.

Preset
Skip

The preset channels can be given the names
you want.

Preset
Name

108

All preset channels = ON

109

109

105

TUNER PHONO

CD

CDR /

TAPE

DVD

VDP

TV

VCR-2

DBS VCR-1

VCR-3

V.AUX

4. Video Setup

2

Component In
Assignment

HDMI/DVI In
Assignment

This assigns the color difference (component) video input
terminals for the different input sources.

The HDMI or DVI-D input terminals are assigned for the
different input sources.
Select HDMI or DVI-D for the monitor output terminal.
Select the HDMI audio signal playback method.

DVD

VDP

TV

1

112

3

Video Convert
Mode

This sets whether or not to use the video conversion
function.

ON

112

111, 112

DBS

VCR-1

VCR-2

VCR-3

V.AUX

1-RCA

2-RCA 3-RCA

4-RCA

5-RCA

6-BNC

NONE

NONE

Audio Delay

Set the audio delay timing to synchronize the sound and
video.

5

0 ms

114

On Screen
Display

This sets whether or not to display the on screen display
that appears on the monitor screen when the controls on
the remote control unit or main unit are operated.

6

Function/Mode = ON, Master Volume = ON, iRadio/mServer = Always, XM = Always,

Screensaver = ON, Display Mode = Mode 1

115

DVD

VDP

TV

DBS

VCR-1

VCR-2

VCR-3

VCR-4

V.AUX

NONE

NONE

NONE

NONE

NONE

NONE

NONE

NONE

4

HDMI/
Component
Out

Set the format of the signal up-converted to the HDMI
monitor output or component video output terminal.

Convert = ON, Scaler = HDMI, Aspect = Full, Resolution = 480p/576p

Color Space = Y Cb Cr, RGB Mode = Normal

113, 114

Aux

0 dB

Net

Audio

EXT.IN-1

Setup

EXT.IN-2

Setup

0 dB

VCR-4

NONE

VCR-4

NONE
