Denon AVR-5805CI User Manual

Page 127

127

Advanced Setup – Part 1

The subwoofer output composition is as shown below.

Subwoofer

Output Composition

1 SP

–

Select this when only one subwoofer is connected.

L/R

Select this when subwoofers are installed on the left and right.

F/B

Select this when subwoofers are installed at the front and rear.

2 SP

LFE/M

Select this to use the subwoofer for both the main channel’s low frequencies and for LFE
low frequencies.

L/R/LFE

Select this when subwoofers are installed on the left and right and you are using a
subwoofer specifically for the LFE.

F/B/LFE

Select this when subwoofers are installed at the front and rear and you are using a
subwoofer specifically for the LFE.

3 SP

The number of channels that can be selected for the different zones is as shown below.

MAIN ZONE

Main

Subwoofer

ZONE2

ZONE4

ZONE3

5.1 CH

1 SP

7.1 CH / 5.1 CH / STEREO / MONO

STEREO / MONO

2 SP

7.1 CH / 5.1 CH / STEREO / MONO

STEREO / MONO

3 SP

7.1 CH / 5.1 CH / STEREO / MONO

STEREO / MONO

7.1 CH

1 SP

7.1 CH / 5.1 CH / STEREO / MONO

STEREO / MONO

2 SP

5.1 CH / STEREO / MONO

STEREO / MONO

3 SP

5.1 CH / STEREO / MONO

STEREO / MONO

9.1 CH

1 SP

5.1 CH / STEREO / MONO

STEREO / MONO

2 SP

STEREO / MONO

3 SP

STEREO / MONO

NOTE:
• The channel settings that can be selected for ZONE2 depend on the channel settings for the MAIN ZONE.
