44

Basic Operation

Playing the input source

1

Select the input source to be played.

• The input source indicator lights.

Example: CD

(Main unit)

(Remote control unit)

To select the input source when ZONE2 SELECT,
ZONE3/4/REC SELECT or TUNING PRESET is
selected, press the SOURCE button on the main unit
then operate the FUNCTION konb.

MATER VOLUME

SOURCE

FUNCTION

MATER VOLUME

HOME THX

CINEMA

ROOM EQ

SPEAKER

MUTE

VIDEO SELECT

FUNCTION

2

Start playback on the selected component.

For operating instructions, refer to the component’s
manual.

3

Adjust the volume.

The volume can be adjusted within the range of –80.0
to +18.0 dB, in steps of 0.5 dB. However, when the
channel level is set (

page 64, 65 or 134), if the

volume for any channel is set at +0.5 dB or greater, the
volume cannot be adjusted up to 18.0 dB. (In this case
the maximum volume adjustment range is “18.0 dB —
(Maximum value of channel level)”.)
Also, you may not be able to adjust the volume to the
maximum of 18.0 dB when internal volume
compensation control is activated due to the
combination of the surround mode and parameters,
downmixing from multi-channel audio signals into two
channels, etc.

(Main unit)

(Remote control unit)

M.VOL. -80.0dB

The volume level is displayed on the master volume
indicator.

2

To choose the surround sound mode

Example: HOME THX CINEMA

Press the

HOME THX CINEMA

button.

For more information about the surround modes (
page 51 ~ 53).

2

To select the Room EQ function

Press the

ROOM EQ

button.

For more information about the Room EQ function
(

page 48).

PHONES

ROOM EQ

MONITOR SELECT

SCALE

VIDEO ON/OFF

SURROUND SPEAKER

HOME THX CINEMA

VIDEO SELECT
