Denon AVR-5805CI - Manual (Page 64)

64
Basic Operation
FUNCTION
MODE
TUNING
BAND
BAND
TUNING
MODE
CURSOR
CH SEL/ENTER
• You can adjust the channel level either according to the
playback sources or to suit your tastes, as described below.
1 Press the CH SEL/ENTER button.
• The “Channel Vol.” screen appears.
2 Press the CURSOR D D , H H or CH SEL/ENTER
button to select the speaker.
The channel switches as shown below each time the
CH SEL/ENTER button is pressed.
Channels which is not used are not displayed.
When the surround back speaker setting is set to
“1spkr” for “Speaker Configuration” (
page 140,
141), this is set to “SB”.
FADER
SRA
SBL SLB SLA
SRB
SBR
FL C FR SW
3 Press the CURSOR F F or G G button to adjust the
level.
The adjustment range for the different channels is
+12.0 dB to –12.0 dB in step of 0.5 dB.
The sound from the subwoofer can be completely cut
by lowering the SW (subwoofer) setting one additional
from –12.0 dB (setting it to “OFF”).
Channel Level
CURSOR
CH SEL/ENTER
TUNER
TU
(AMP mode)
(TUNER mode)
