Denon AVR-5805CI User Manual
Page 134
134
Advanced Setup – Part 1
Volume Limit:
Set the upper limit for the volume for the different
zones.
• –20 dB, –10 dB, 0 dB:
The volume cannot be increased above the
selected levels.
• OFF:
If you do not want to set a volume limit, select
“OFF”.
In this case, the volume can be set to the AVR-
5805CI’s maximum volume (output) level of +18
dB, which is extremely loud.
2
Press the
CURSOR
D
D or H
H button to select the
desired setting, then press the
CURSOR
F
F or G
G
button to select the parameter.
Setting the Volume Control
• Set the upper limit for the volume, the volume level when
the power is turned on, and the volume level when the mute
mode is set for the each zones.
1
Press the
CURSOR
D
D or H
H button to select
“Volume Control” at the “Option Setup”
menu, then press the
ENTER
button.
• The “Volume Control” screen appears.
Power On Level:
Set the volume that is set when the power is
turned on for the different zones.
You can adjust the volume level within the range of
–80 to +18 dB in steps of 1.0 dB.
• – – – (Mute)
The volume is always muted when the power is
turned on.
• LAST
The volume set when the AVR-5805CI was last
used is stored in the memory and set when the
power is turned on.
3
Press the
ENTER
button to enter the setting.
• The “Option Setup” menu reappears.
Mute Level:
Set the volume attenuation level when the mute
mode is set for the different zones.
• FULL
The volume is fully muted.
• –40 dB
The volume is lowered 40 dB from the current
level.
• –20 dB
The volume is lowered 20 dB from the current
level.
Volume Level:
Set whether to fix the output level for the different
zones or make it variable.
• VAR (variable)
The level can be adjusted freely using buttons on
the remote control unit.
• –40 dB, 0 dB
The output level is fixed at the set level and the
volume can no longer be adjusted.
• For ZONE2, ZONE3 and ZONE4 the “Volume Limit” and
“Power On Level” can be set when “Variable” is selected
for “Volume Level”.
• When the power amplifier is assigned to either of the
ZONE2, ZONE3 and ZONE4 channels at “Power Amp
Assign”, “–VAR–” (only variable) is displayed and the fixed
level cannot be set.
