Denon AVR-5805CI - Manual (Page 124)

124
Advanced Setup – Part 1
1 Press the CURSOR D D or H H button to select
“Audio Delay” at the “Video Setup” menu,
then press the
ENTER button.
• The “Audio Delay” screen appears.
2 Press the CURSOR F F or G G button to set the
delay time (0 ms ~ 200 ms).
With a movie source, for example, adjust so that the
movement of the actors’ lips is synchronized with the
sound.
3
Press the ENTER button to enter the setting.
• The “Zone Setup” menu reappears.
2 Audio Delay (ZONE2)
• Set the delay time the sound is synchronized with the
picture which are output in ZONE2.
Setting the ZONE3 and ZONE4 tone control
and channel level
• Adjust the tone and channel level of the sound output from
ZONE3 and ZONE4.
1 Press the CURSOR D D or H H button to select
“Zone3/4 Tone/Ch Lev.” at the “Zone Setup”
menu, then press the
ENTER button.
• The “Zone3/4 Tone/Ch Lev.” screen appears.
2 Press the CURSOR D D or H H button to select the
zone whose sound you want to adjust (ZONE3,
ZONE4), then press the
ENTER button.
• Switch to the setting screen.
Example: When “Zone3” is selected
3
Press the CURSOR D D or H H button to select the
item to be set, then press the CURSOR F F or G G
button to adjust the parameter.
Bass:
Adjust the tone for the bass. (The bass sound can
be adjusted between –12 dB and +12 dB in steps
of 2.0 dB.)
Channel Level:
Set so that the playback level is the same for the
left and right channels. (The volume can adjusted
between –12 dB and +12 dB in steps of 1.0 dB.)
Treble:
Adjust the tone for the treble. (The treble sound
can be adjusted between –12 dB and +12 dB in
steps of 2.0 dB.)
HPF:
Set this to “ON” if your speakers do not have a
very strong capacity for producing low bass. Using
the high pass filter makes it possible to reduce
distortion of the bass sound.
Press the ENTER button.
• The “Zone3/4 Tone/Ch Lev.” screen reappears.
Use the same procedure to make the settings for ZONE4.
4
