Denon AVR-5805CI - Manual (Page 144)

144
Advanced Setup – Part 2
3 Press the CURSOR D D or H H button to select
“Test Tone Start”, then press the CURSOR F F
button to select “Yes”.
4
-1
When “Auto” mode is selected:
Press the
CURSOR F F or G G button to adjust all
the speakers to the same volume.
• The test tones are emitted from each speaker in the
following order, at 4 seconds intervals the first time
and second time around, 2 seconds intervals the
third time around and on:
The volume can be adjusted between –12.0 dB and
+12.0 dB in units of 0.5 dB.
4
-2
When “Manual” mode is selected:
Press the
CURSOR D D or H H button to select the
speaker, then press the CURSOR F F or G G button
to adjust all the speakers to the same volume.
Example: “Manual” mode is selected.
5 Press the ENTER button to enter the setting.
• The “Channel Level” screen reappears.
FL
SW
1spkr
2spkrs
C FR SRA
SBL SLB SLA
SB
SRB
SBR
When the surround back speaker setting is set to
“1spkr” for “Speaker Configuration”, this is set to
“SB”.
Example: When the volume is set to –11.5 dB while
the test tone is being produced from the
Front L ch speaker
• To cancel the settings, press the CURSOR F F button to select
“Level Clear” and “Yes” on the “Channel Level” screen,
then make the settings again.
