Denon AVR-5805CI User Manual
Page 100
100
Advanced Operation
1
Press the
ZONE3/4/REC SELECT
button until
“ZONE3 SOURCE” appears on the display.
2
With “ZONE3 SOURCE” displayed, turn the
FUNCTION
knob until “RECOUT SOURCE”
appears on the display.
• The REC indicator lights.
R E C O U T S O U R C E
D V D
2
Playing one source while recording another
(REC OUT mode)
2
Recording Dolby Digital and DTS multi channel
sources
• With this set it is possible to record Dolby Digital and DTS
multichannel signals converted into 2 channel analog
signals.
• The recording signals are output to the TAPE and VCR
output terminals.
• Down-mixed analog signals converted into digital signals
are output from the OPTICAL 3, 4 and 5 digital output
terminals at this time.
1
Press the
ZONE3/4/REC SELECT
button until
“RECOUT SOURCE” appears on the display.
2
Press the
INPUT MODE
button to set the input
mode according to the source to be played.
3
Press the
DIRECT/STEREO
button to set the
surround mode.
• The multichannel digital signals are down-mixed and
output to the TAPE and VCR output terminals.
4
Set the recording mode.
• To cancel, turn the FUNCTION knob and select “SOURCE”.
• Recording sources other than digital inputs selected in the
REC OUT mode are also output from the ZONE3 audio/video
terminals.
• When the REC OUT mode is selected, the ZONE3 button on
the remote control unit cannot be operated.
ZONE3 SOURCE
ZONE3 TUNER
····
····
ZONE3 V.AUX
RECOUT SOURCE
RECOUT VCR-4
RECOUT V.AUX
The function switches as shown below when the
FUNCTION knob is turned.
3
With “RECOUT SOURCE” displayed, turn
the
FUNCTION
knob to select the source you
wish to record.
4
Set the recording mode.
• Start recording.
For operating instructions, refer to the manual of the
component on which you want to record.
NOTE:
• This function does not work when “5.2 ch / 5.3 ch” is set
for the MAIN ZONE’s channel setup.
INPUT MODE
DIRECT/STEREO
ZONE3/4/REC SELECT
POWER
FUNCTION
PHONES
STANDARD
INPUTMODE
HOME THX CINEMA
DIRECT/STEREO
Multi-source recording / playback
