Placing Film or Slides
Removing the Document Mat
Placing Slides in the Holder
Placing Film in the Holder
Replacing the Document Mat
Removing the Document Mat
To scan film strips or slides, you need to remove the document mat from the scanner cover. This
uncovers the transparency unit window so your scanner can use it to scan your film or slides.
Make sure the cover cable is connected to the scanner’s OPTION port.
Note:
Before connecting or disconnecting the cover cable, turn off the scanner using its
power switch.
Open the scanner cover and gently slide up the document mat to remove it. Also make
sure the transparency unit transportation lock is unlocked.
