Interface

One USB 2.0 Hi-speed port

Light source

White LED, IR LED

* Optical Resolution is the maximum scan resolution of the CCD elements, using the

definition of ISO 14473. ISO 14473 defines optical resolution as the fundamental

sampling rate of the scan sensor.

Mechanical

Dimensions

Width: 18.7 inches (475.0 mm)

Depth: 10.7 inches (272.0 mm)

Height: 4.4 inches (113.0 mm)

Weight

Approx. 8.8 lb (4.0 kg)

Electrical

Note:

Check the label on the AC adapter or on the back of the scanner for voltage
information.

Scanner

Rated voltage

DC 24.0 V

Rated input current

1.3 A

Power consumption

16.0 W (17.5 W with ADF) Operating

7.5 W (6.5 W with ADF) Ready Mode

4.0 W Sleep Mode

0.4 W Power off

AC Adapter

100-120 V model

220-240 V model
