Section Seven –Electrical System Service Operations
Fluorescent Lamp
Lamp Identification
121
Changing the Fluorescent Lamp
121
Lamp Socket Replacement
122
Optional Ultraviolet Lamp
Lamp Identification
122
UV Lamp Specifications
122
Changing the UV Lamp
123
Lamp Socket Replacement
123
Electronics Module Access
124
Electronic Module Component Identification
124
Circuit Breaker
Resetting a circuit breaker
125
Circuit breaker specifications
125-26
Testing a circuit breaker
126
Replacing a circuit breaker
126
Power Supply Board Service Operations
Fuse Testing & Replacement
127
Display Board Service Operations
128
Touchpad Connections
128
Diagnostic Operations
129
Motor Service Operations
Motor Testing
129-31
Motor Output Signal Testing
132
Wiring Diagrams
133-34
Section Eight – Purifier Logic+ Accessories
Ventus Canopy Connection Kit
135-41
Air Flow Sensor Kit
142-45
Service Fixture Kit
146-47
U.V. Lamp Kit
148-50
I.V. Bar Kit
151
Prefilter Kits
152-53
RS-232 Connection Kits
155-65
Using the RS-232 Receptacle
158
Connection for Computer Interface
158
Logic+ Relay Contact Outputs
161-64
Section Nine - Miscellaneous
Troubleshooting
166-69
Purifier Logic Replacement Parts
170-71
Dimensions
172
