Work surface removal, Grille removal – Labconco PURICARE Procedure Station Models 31260 User Manual
Page 116
Product Service 1-800-522-7658
116
Work Surface Removal
Note: The work surface of the cabinet must be thoroughly decontaminated before
removing it.
1.
Lift the front edge of the work surface straight up by grasping the knob handles at
either front corner.
2.
Pull the work surface straight out, letting its rear edge rest on the center support
underneath.
3.
Reinstall the work surface by resting the bottom on the center rail while pushing it
back into the cabinet. Be sure to engage the tabs on the back corners of the work
surface with the slots on the rear wall of the work area.
Grille Removal
Note: The grille must be thoroughly decontaminated before removing it.
1.
Remove the work surface as described earlier.
2.
At one end of the grille, grip the front of grille with one hand, and the back with
the other hand. Pivot that end of the grille upward and inward, paralleling the
angle of the sash, as shown in Figure 6-31.
3.
Pull the other end of the sash up and away from the bottom edge of the cabinet.
4.
Reinstall the grille by reversing the above sequence, ensuring that the grille
properly engages the bottom edge of the cabinet.
Figure 6-31
