Labconco PURICARE Procedure Station Models 31260 - Manual (Page 150)

Product Service 1-800-522-7658 150
20. The first screen allows you to set the Type of cabinet. Leave this
setting alone, and press OK/Mute.
21. The second screen allows you to configure the cabinet for a
canopy or not.* Leave this setting alone, and press OK/Mute.
22. This screen configures the unit for a UV light or not. Select “to
have a UV Light”, and then press OK/Mute , the unit will shut off
and then reset in the new configuration.
Refer to the user’s manual for further information regarding the proper operation
and maintenance of the UV light.
Configuration
Type A Canopy Option
This cabinet has:
or to choose,
OK to select, MENU to escape
a canopy
 no canopy
 
This Logic is configured:
or to choose,
OK to select, MENU to return
to have a UV light
 to NOT have a UV light
 
UV Settings
