QuickChart – Cell Logic+ Type A2 BSCs Metric
Units
Model 32239
33239
34239
32249
33249
34249
32259
33259
34259
32269
33269
34269
Type A2 A2 A2 A2
Cabinet Size (in m) .91 1.22 1.52 1.83
Sash Opening (mm) 229 229 229 229
Starting Serial # 1303_ 1303_ 1303_ 1303_
Downflow Data
Nominal Avg. Downflow (m/s) .279+/.03 .279 +/-.03 .279+/.03 .279 +/-.03
grid # of points (rows x columns) 21 (3x7) 24 (3x8) 30(3x10) 36(3x12)
Grid distance from back & sides (mm) 152 152 152 152
Distance between rows (mm) 141 141 141 146
Distance between columns (mm) 104 132 137 140
Inflow Data
Nominal Average Inflow (m/s) .533+/-.03 .533+/-.03 .533+/-.03 .533+/-.03
Sash Open Area (Sq. m) .212 .282 .351 .421
Nominal Avg. Exhaust Vol. (m3/s) .113 .150 .187 .224
Avg. Exhaust Vol. Range
(m3/s)
.108-.118 .143-.157 .178-.196 .214-.235
Secondary Inflow Data
3
Sash Opening Template 1 3+ 4+ 5+ 6+
Sensor distance (inches) 2 102 83 83 102
# of Test points 6 8 10 12
Test point location * * * *
Nominal Avg. Inflow Vel. (m/s) 1.22 1.62 2.02 1.32
Avg. Inflow Vel. Range (m/s) 1.16-1.28 1.54-1.69 1.92-2.11 1.26-1.38
Correction Factor (CF) .0929 .0929 .0929 .1700
Average Inflow Volume Range
(AIV) (Avg. velocity x CF)
.108-.118 .143-.157 .178-.196 .214-.235
Sash Open Area (Sq. m) .212 .282 .351 .421
Inflow Velocity Range
(AIV / Sash open area)
.533+/-.03 .533+/-.03 .533+/-.03 .533+/-.03
HEPA Filter Leak Test Data
Air Displacement (m3/s) 596 794 991 1189
Laskin Nozzles needed 1 2 2 2
Theoretical aerosol conc. (ug/l) 3 23 34 27 23
Actual aerosol conc. (ug/l) 4 12 18 15 15
Supply HEPA Data
Width x Depth x Height (in.) 5 36x18x3.06 48x18x3.06 60x18x3.06 72x18x3.06
Performance (CFM) 335 445 555 665
Performance (Pressure in. H
2
O) < .60” <.45” <.45” <.42”
Labconco P/N 3838400 3838401 3838402 3838403
Exhaust HEPA Data
Width x Depth x Height (in.) 5 18x18x5.88 26x18x5.88 36x18x5.88 48x18x5.88
Performance (CFM) 266 353 441 529
Performance (Pressure in. H
2
O) < 0.35” < 0.28” < 0.28” < 0.28”
Labconco P/N 3838500 3838501 3838502 3838503
Motor/Blower Data
Labconco P/N 6 3832200 3832201 3832207 3832208
Motor HP ½ ½ ¾ ¾
Fluorescent Lamp Data
Fluorescent Lamps (2 each) F25T8 TL741 F32T8 TL741 F40T8 SP41 F40T8 SP41
Fluor. Lamp Labconco Part # 9721901 9721900 9721903 9721903
Fluor. Ballast Labconco Part # 3838100 3838100 3838100 3838100
Ventus Canopy Data
Labconco Canopy P/N 3889200 3889201 3889202 3889203
Canopy Slot Area (m 2 ) .12 .12 .12 .12
Canopy Inflow Range (m/s) 20-100 20-100 20-100 20-100
Nominal Canopy Slot Velocity (m/s) 240-260 240-260 240-260 240-260
Nominal Canopy Slot Volume
(m3/s)
50 50 50 50
Canopy Vacuum (Pa) 0.1-0.15 0.1-0.15 0.1-0.15 0.1-0.15
