77
Fig 9H
Fig 9G
J. Tighten the two (2) 1/4-20 screws securing
the air box to the air box bracket, as well as
the 1/4-20 screw securing the pedestal mount
to the air box. See fig 9G, 9H.
K. Tighten the hose clamps attaching the reduc-
ing coupler to the air box and the MAF hous-
ing.
