62
M. Connect the MAP sensor connector to the
MAP sensor at the front of the lower mani-
fold. See fig 8P.
N. Connect the EVAP connector to the EVAP
solenoid. See fig 8Q.
O. Connect the ETC extension harness to the
throttle body. See fig 8R.
Fig 8Q
Fig 8R
Fig 8P
