East Coast Supercharging Lysholm 2010+ Camaro Supercharger Kit - Manual (Page 62)

P/N: 4LGE020-010 v1.1, 2011-04-29
© 2011 Lysholm
All Rights Reserved, Intl. Copr. Secured
52
F. Mount OEM EVAP solenoid and bracket
using the supplied M8x1.25 x 8mm button
head with supplied washer to the ground
plate, as shown. See fig 7K.
Fig 7K
Fig 7L
Fig 7J: EVAP Solenoid and bracket shown
mounted to ground plate.
M8X1.25X8MM
W/ WASHER
GROUND WIRE
