AL. Locate the OEM EVAP line that was originally
attached to the EVAP solenoid and the intake
manifold behind the throttle body. Using a
utility knife, carefully cut the nylon tubing and
remove the 90º fitting. See fig 8AJ.
AM. Cut a 23” long section of the supplied 5/16”
fuel hose.
AN. Insert a supplied 14.5 stepless clamp on one
end of the hose and attach the 90º fitting.
Secure the fitting by compressing the clamp
ear. Install the connector on the gray side of
the EVAP solenoid as shown. See fig 8AK.
Fig 8AK
Fig 8AL
Fig 8AJ
