16
AF. Remove the eight (8) forward most of the ten
(10) 8mm headed screws securing the intake
manifold to the cylinder heads. To simplify
removal of the intake manifold, use tape to
temporarily hold the rear two screws in an
elevated position. See fig 1AS.
Fig 1AQ
Fig 1AR
Fig 1AS
