M. Washer reservior removal
1. Locate the windshield washer reservoir
(under the driver side headlight) and dis-
connect the electrical connector from the
pump.
2. Drain the reservoir by removing the
pump from its grommet and retaining
saddle and catching the fluid in a large,
clean open container or funnel as shown
in Fig 1Q. Keep the fluid for later reuse.
3. Remove the washer hose from the 90º
fitting near the pump and free it from the
attachment points on the reservoir.
4. Remove the grommet from the reservoir
and retain for later use.
5. Remove the three (3) 13mm-headed
screws mounting the windshield washer
reservoir and set the reservoir aside.
See fig 1R. It will be replaced in a later
step. Set one (1) of the 13mm headed
screws aside for future use.
Fig 1R
Fig 1Q
